Distribution Transformer Tests

- Core insulation tests

- Operational checks on protection system

- Insulation resistance (IR) measurement

- Capacitance and dissipation factor

  (tanδ) measurement of bushings.

- Capacitance and dissipation factor

  (tanδ) measurement of windings

- Turns ratio (Voltage ratio) measurement

- Vector Group and Polarity

- Winding resistance measurement

- Magnetic Balance test

- Floating neutral point measurement

- Measurement of short-circuit impedance

- Exciting / Magnetizing current

  measurement

- Vibration measurement of oilimmersed

  reactor

- Operational check on OLTCs

- Stability of differential, REF of

  transformer / reactor

  bushing current transformers tests

- Frequency response analysis (FRA)

  measurement

- Dissolved gas analysis (DGA) of oil

  sample

- Thermovision infrared scanning

Testing and Commissioning

Protection Relays Tests

- Wiring diagram check

- General equipment inspection

- Insulation resistance measurement

  relay self-test and

  external communications checks on

  digital/numerical relays

- Measurement test

- Trip settings test

- Secondary injections

- Primary injection tests

- Protection scheme logic test.



Testing and Commissioning

Metal Glad Switchgear Testing

- Mechanical Checks and Visual

  Inspection

- Insulation Resistance Test

- Contact Resistance Test

- High Voltage Test
